Connections
|
SDI Video Input
1 x 10 bit SD/HD switchable.
SDI Video Output
1 x 10 bit SD/HD switchable.
HDMI Video Input
1 x HDMI type A connector.
HDMI Video Output
1 x HDMI type A connector.
Talkback Audio
1 x 3.5mm stereo connector for talkback microphone. 1 x 3.5mm stereo connector for stereo headphones, compatible with iPhone headsets. |
Analog Audio
2 x balanced 1/4" TRS connectors (stereo) microphone level in. When connected, replaces audio from SDI In or HDMI In.
Optical Fiber Video Input
1 x single mode SD/HD switchable with LC connector.
Optical Fiber Video Output
1 x single mode SD/HD switchable with LC connector. |
Optical Fiber Audio Input
1 x single mode camera audio inputs with LC connector. Channels 1 & 2 are camera audio. Channels 15 & 16 are intercom audio.
Optical Fiber Audio Output
1 x single mode camera audio outputs with LC connector. Channels 1 & 2 are camera audio. Channels 15 & 16 are intercom audio.
Computer Interface
1 x mini-B type?USB 2.0?connector for initial setup, firmware updates and Converter Utility software control. |
Standards |
SDI Format Support
525i59.94 NTSC, 625i50 PAL?
720p50, 59.94, 60?
1080p23.98, 24, 25, 29.97,30, 50, 59.94, 60?
1080PsF23.98, 24, 25, 29.97, 30?
1080i50, 59.94, 60
2K Format Support
1080p23.98, 24, 25?
1080PsF23.98, 24, 25?
2K 23.98PsF, 24PsF, 25PsF |
HDMI Format Support
525i59.94 NTSC, 625i50 PAL?
720p50, 59.94, 60?
1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60?
1080PsF23.98, 24, 25, 29.97, 30?
1080i50, 59.94, 60
SDI Compliance
SMPTE 259M,?SMPTE 292M.
Audio Sampling
Television standard sample rate of 48Khz,?24 bit?A/D conversion.. |
Video Sampling
4:2:2
Color Precision
10-bit
Color Space
REC 601, REC 709
Multiple Rate support
SDI and HDMI are switchable between between standard definitlon and high definition |
